Rapidox SF6 7100 Bench Gas Analyser
Product Information
The Rapidox SF6 7100 Bench gas analyser is designed for controlling and monitoring the quality of SF6 gas over a range of applications, including medium & high voltage gas insulated electrical equipment, SF6 gas purity tests, medical testing, manufacturing and laboratory-based research and development.
Exceptionally accurate and stable readings are achieved in simultaneous analysis and data-logging of SF6, SO2 and H2O (dew point) gases. Fully compatible with the Rapidox Gas Recovery Bag, a gas output nozzle allows for the analyser to be attached, ensuring that all SF6 gas is recovered.
Read MoreProduct Information
The Rapidox SF6 7100 Bench gas analyser is designed for controlling and monitoring the quality of SF6 gas over a range of applications, including medium & high voltage gas insulated electrical equipment, SF6 gas purity tests, medical testing, manufacturing and laboratory-based research and development.
The Rapidox SF6 7100 Bench analyser is available as a complete instrument with a swing carry handle or as a 19″ cabinet rack mount format for industrial applications. Options include a set of genuine DN8 and DN20 fittings with a stainless steel braided hose (self-sealing couplings) and a separate thermal printer.
An optional pump enables two modes of operation. For SF6 sources at atmospheric pressure or below, the pump is activated to draw a sample through the analyser. Alternatively, the pump can be deactivated when sampling SF6 from a pressurised gas compartment up to 10 bar on the inlet. Gas flow is regulated manually via a rotary knob on the fascia and displayed electronically on the screen.
Features
- Rapid measurement response of 3-4 minutes at 20°C.
- Low maintenance sensors.
- Fully programmable alarm circuits.
- Programmable analogue outputs.
- RS232/RS485 communications and complete data-logging software.
- Optional long-life variable speed sample pump.
- Large back-lit LCD display.
- Password protection.
- Operates on any worldwide mains voltage (90-260VAC).
- Compatible with industry standard gas recovery systems.
Product Resources
Product Specification
| Gas | Range | Accuracy Range |
|---|---|---|
| SF6 (Sulphur Hexafluoride) | 0-100% | ±0.5% full-scale accuracy |
| H2O (Dew Point) | -60°C to +20°Cdp | ±2°Cdp accuracy of reading |
| SO2 (Sulphur Dioxide) | 0-100ppm to 0-2000ppm | ±2% full-scale reading |
| HF (Hydrogen Fluoride) | 0-10ppm or 0-20ppm | ±2% full-scale reading |
| CF4* (Tetrafluoromethane) | 0-80% | ±1% of reading |
| H2S (Hydrogen Sulphide) | 0-200ppm to 0-2000ppm | ±2% full-scale |
| CO (Carbon Monoxide) | 0-500ppm to 0-5000ppm | ±2% full-scale |
| O2 (Air Content) | 0-100% | ±5% full-scale based on oxygen component |
